How Does an Air-Cooled Chiller Work?

The air-cooled chiller is mainly composed of four core components: radiator, condenser, expansion valve and evaporator. These four components work together to form a complete refrigeration cycle.

The Working Process of Refrigeration Cycle

The initial stage of the refrigeration cycle is the compression process. At this juncture, the refrigerant is drawn into the compressor, where it undergoes a significant increase in temperature and pressure. The refrigerant transitions from a low-temperature, low-pressure vapour state to a high-temperature, high-pressure vapour state.

The compressed refrigerant vapour, subjected to high temperatures and pressures, enters the condenser. The condenser is a radiator that cools the refrigerant vapour into a high-pressure liquid through forced draft by a cooling fan. The condenser dissipates heat to the surrounding air, transforming the refrigerant vapour into a high-temperature and high-pressure liquid.

The high-pressure liquid refrigerant is introduced to the evaporator via the expansion valve. The function of the expansion valve is to regulate the flow of refrigerant by throttling and reducing the pressure. The expansion valve enables the high-pressure liquid to expand into a low-temperature and low-pressure liquid, resulting in a notable reduction in temperature and pressure.

The low-temperature and low-pressure refrigerant liquid is introduced into the evaporator. The refrigerant liquid within the evaporator evaporates rapidly, absorbing heat from the surrounding environment, including the heat from the cooling water. The temperature of the cooling water is reduced through the process of evaporative heat transfer. Concurrently, the low-temperature and low-pressure refrigerant liquid undergoes evaporation, forming a low-temperature and low-pressure vapour. Once the aforementioned process is complete, the refrigerant vapour is drawn into the compressor once more, thereby initiating a new refrigeration cycle.

The Role of Cooling Fan

The cooling fan in the air-cooled chiller is a critical component. The forced ventilation system ensures the rapid dissipation of heat from the refrigerant vapour on the condenser surface, while accelerating the evaporation of the refrigerant liquid on the evaporator surface. This optimises the cooling effect.

The Key Benefits of Air-Cooled Chillers

The product has been designed with energy saving in mind. The use of a high-efficiency compressor and an optimised design will result in effective reduction of energy consumption and waste.

Environmental protection is a core value for our company. The use of environmentally friendly refrigerant ensures that the product is environmentally friendly and does not pollute the air or the earth.

The product is designed to be stable. The product is manufactured using advanced technology and high-quality raw materials, resulting in a stable performance and long service life.

The product is designed for easy maintenance, featuring a simple structure and convenient maintenance procedures that reduce overall maintenance costs.

Application

Air-cooled chillers are suitable for a variety of locations that require cooling, including factories, warehouses, shopping malls, offices, and other commercial premises. Air-cooled chillers are particularly suited to industrial environments where cooling is required for a large area. They can rapidly and effectively reduce indoor temperatures, thereby improving the working environment and employee work efficiency.

Air-cooled chillers are designed to achieve refrigeration effects through the coordinated work of core components, including compressors, condensers, expansion valves and evaporators. The phase change process of the refrigerant is utilised to transfer heat from the cooling water, thereby accelerating the heat dissipation and evaporation process through the cooling fan. Air-cooled chillers are an essential component in a wide range of cooling systems, offering high efficiency, stability, environmental protection and straightforward maintenance.
